The Jewell Instruments LCF-2330 Series inclinometer is a rugged, dual axis instrument optimized for high accuracy and superior repeatability. With input ranges from ±1° to ±90°, the LCF-2330 utilizes Jewell's fluid damped, flexure suspension, servo technology in a small, convenient package for applications requiring a compact, dual axis solution.

LCF-2330 series inclinometers are solid-state, closed loop meters with accuracy, stability, and reliability several orders of magnitude greater than open loop types. They are fully self-contained and designed to operate from standard DC power source with output of 0 to ±5 VDC directly proportional to the sine of the angle of tilt. Features include micro radian resolution, internal temperature sensor, high level ±5 Vdc output, low impedance output, 12-18 VDC input, operating temperature -40 to 80°C, and ability to withstand shocks over 1000g and vibration to 20 grms. Applications: 2-axis machine tool leveling, bridge structural monitoring, submersible control feedback, offshore platform stability, antenna leveling, weapons platform leveling, deviation surveys.
